Stormproof Hinge Marine Grade 316 Stainless Steel
Code: HB2355SS
A marine grade 316, satin stainless steel finish stormproof timber casement hinge. Hinges are sold individually, complete with fixings.
Hinges are simply bearings or movable joints, that sit on a door, a lid or a gate and allow it to swing open or closed. There are so many different types of hinges available but the most common is the morticed (also known as recessed) butt hinge. A joiner will make two small spaces, known as mortices, in the door frame and the door for the hinge flaps/leaves to sit in, so these lie flat together and only the hinge knuckle is visible when the door is closed.
When measuring your hinge, make sure that you lie it open and measure the width and height across the entire hinge, not just a single leaf.
Choosing a hinge can seem a bit of a daunting task but it does not have to be. Firstly, you need to consider where you will be fitting your hinge. Is it for a counter flap, is it for a gate, is it for a toilet cubicle or is it for a door? If it is for a door, is it a lightweight door, is it a fire door, is it an internal door? By answering all these questions, you will be able to work out what type of hinge, what grade of hinge, what finish, what size of hinge and how many hinges you will need.
At Door Controls Direct we pride ourselves on providing you with the best quality door hinges at great prices. We have carefully selected products to suit each of your requirements, for both internal and external timber doors and for both light and extensive use. All our staff are on hand to offer advice if you need it and we have a specification department for larger projects. Please call our knowledgeable team on 01305 263300. We supply door hinges for a huge range of door applications. For fire door butt hinges, we can supply CE marked products compliant to BS EN 1935 standards including the HOPPE range. Please note – grades vary on each hinge type so click through on each listed product for the extra information you require.
Hinges Grades Explained:
Hinge Grade |
Usage |
Test Cycles |
Door Mass |
1 |
Window |
10,000 |
10Kg |
2 |
Window |
10,000 |
20Kg |
3 |
Window / Door |
25,000 |
20Kg |
4 |
Door |
200,000 |
20Kg |
5 |
Window |
10,000 |
40Kg |
6 |
Window / Door |
25,000 |
40Kg |
7 |
Door |
200,000 |
40Kg |
8 |
Window |
10,000 |
60Kg |
9 |
Window / Door |
25,000 |
60Kg |
10 |
Door |
200,000 |
60Kg |
11 |
Door |
200,000 |
80Kg |
12 |
Door |
200,000 |
100Kg |
13 |
Door |
200,000 |
120Kg |
14 |
Door |
200,000 |
160Kg |
Read More
Categories
Brand
Fire Rated
Application
Colour/Finish
Grade of Stainless Steel
Price
Code: HB2355SS
A marine grade 316, satin stainless steel finish stormproof timber casement hinge. Hinges are sold individually, complete with fixings.
Code: DCGBXDAPS
Geze Boxer satin stainless steel double action pivot set with double action top centre, double action bottom strap, double action bottom pivot and intumescent fire pack.
Code: HB1590SS
The ARRONE AR8580 is a fully concealed, maintenance free, low friction hinge. It is Grade 13, manufactured from Grade 304 satin stainless steel and measures 102mm x 76mm. This hinge is fire-rated and suitable for a maximum adjusted door weight up to 120kg.
Code: HB1568SS
The ARRONE AR8187 is a high performance, low friction ball-bearing hinge. It is Grade 13, fire-rated and suitable for a maximum adjusted door weight of up to 120kg. This hinge measures 102mm x 76mm and has a satin stainless steel finish.
Code: HB1166SC
The Carlisle Brass HDSSW washered butt hinge is great for domestic applications. Select from two sizes and two finishes. Hinges are sold as singles, not pairs.
Code: HB1066SC
The Carlisle Brass FTD800D is a non-washered cabinet hinge. Choose from one of three finishes. Hinges are sold as singles, not pairs, complete with fixings.
Code: CH10645
The Chameleon range of friction hinges are available for side hung or top hung applications, in a variety of sizes. All friction hinges are supplied as pairs.
Code: DC8550
The DORMA 8550 is a floor pivot set (end-load installation) for use with transom door closers and top rails with a minimum 21mm channel depth and 35mm width.
Code: HB1548PS
A polished stainless steel ball bearing butt hinge which is 'CE' marked, grade 13 and measures 102mm x 76mm x 3mm. Hinges are sold as singles, not pairs, complete with fixings.
Code: HB1516SS
The Eurospec HIP1332 plain bearing stainless steel butt hinge is non-washered, complete with fixings.
Code: HB1568SS-316
The Eurospec ENDURO CEN1433 Grade 13 Stainless Steel Ball Bearing Hinge is manufactured from Marine Grade 316 Stainless Steel.
Code: HB1468SS
The Royde and Tucker H102 hi-load hinges are sold as singles, not pairs, complete with fixings. Select from square or radiused corners and BZP or satin stainless steel finish.
