GEZE TS5000 Slide Arm Door Closer

GEZE TS5000: Versatile Door Closer for Single Action Doors

The GEZE TS5000 slide arm door closer is suitable for use on single action doors with up to 1400mm leaf widths. It is CE marked and Certifire Approved CF 145. This GEZE door closer also comes with adjustable closing speed, latching action, backcheck and power size EN 2-6.

Designed to meet the demands of modern buildings, this surface mounted overhead door closer with a guide rail offers performance and flexibility, making it ideal for a wide range of applications, including fire and smoke protection doors.

Key Product Features:

• Two models available:

          GEZE TS5000 for Fig. 1/61 – Pull side mounting/push side transom mounting
          GEZE TS5000L for Fig. 66/9 – Push side mounting/pull side frame mounting

• Closing force of EN 2-6 with variable adjustment
• Fully certified to BS EN 1154
• Suitable for up to 1400mm wide door leafs
• Can be used for right and left hand single action doors without conversion
• Certifire approved - CF145 certificate
• For fire and smoke protection doors – 120 minute fire rating
• Hydraulic latching action
• Adjustable closing speed
• Integrated backcheck
• Visual closing force display
• All functions can be set from the front
• Silver finish
• Body dimensions: 287mm x 47mm x 60mm

Creating a Consistent Aesthetic with GEZE TS5000 Series

This GEZE door closer is offered in two models, each designed for a specific mounting option. You can choose the appropriate model using the drop down menu.

Here’s a closer look at the options:

• GEZE TS5000 Door Closer Fig. 1/61

          Fig. 1 - Pull side mounting, also known as hinge side mounting, where the door closer is installed on the door leaf on the side with visible hinge knuckles.

          Fig. 61 - Transom mounting, where the door closer is installed on the door frame of the side without visible hinge knuckles.

• GEZE TS5000L Door Closer Fig. 66/9

          Fig. 66 - Push side mounting, or opposite hinge side mounting, where the door closer is installed on the door leaf on the side without visible hinge knuckles.

          Fig. 9 - Pull side transom mounting. where the door closer is installed on the door frame of the side with visible hinge knuckles.

These options allow you to maintain a consistent appearance in a corridor with multiple doors, even if some open inward and others outward. By using the appropriate model for each door, you can ensure all door closers are installed on the same side, creating a uniform look throughout the corridor. A separate soffit angle bracket, or lintel casing bracket is also available for opposite hinge side mounting on single action doors.

If you require a door closer with electromagnetic hold open for fire rated doors then the GEZE TS5000E is available to complement these closers.

Stylish and Functional Design

This GEZE door closer features a guide rail design. Unlike protruding scissor arms, the slide channel design is both aesthetically pleasing and highly functional. The absence of a scissor arm not only enhances the visual appeal of the door closer but also reduces the risk of damage or misuse, making it an ideal choice for environments such as schools, hospitals, and public buildings where durability and safety are paramount.

For installations in particularly vulnerable areas, the GEZE Boxer range offers concealed options that further protect the door closer from potential harm.

The GEZE TS5000 for Fire Doors

The GEZE TS5000 door closer is Certifire Approved and designed to accommodate fire and smoke protection doors with a 120 minute fire rating. This certification ensures that the door closer can withstand high temperatures and maintain its functionality during a fire, contributing to the overall safety of the building.

The GEZE Solution for Every Door

GEZE provides an extensive selection of door closers, including overhead closers, concealed closers, and floor springs. Whether you're looking for a discreet design or a robust, heavy duty option, GEZE has the right solution for every door.

Explore our range of door closers or contact our team for expert technical advice.
