ARROW BM3SE Door Closer: The Ideal Solution for Safety and Compliance

The BM3SE closer is British made and designed to meet the needs of modern facilities, particularly in schools, public buildings, and commercial environments. This door closer not only focuses on accessibility and user experience but also plays a crucial role in maintaining fire safety and regulatory compliance.

The BM3SE closer features a fixed power size EN 3, suitable for doors up to 950mm wide. It supports compliance with BS 8300 and Approved Document M for accessibility and is approved for use on fire doors with up to 60 minutes of fire resistance.

This door closer is available with either the hold open or swing free function; simply use the drop down menu to select your preference.

Key Product Features:

• Hold open or swing free function
• Fixed power size EN 3
• Fig. 1 pull side mounting
• Suitable for doors up to 60kg and 950mm wide
• Operating voltage: 24V DC 85mA 2 Watts
• Adjustable latch action and closing speed
• Tested to BS EN 1154 and 1155
• Assists with BS 8300 for accessibility
• Tested to BS EN 1634 for use on fire rated doors up to 60 minutes
• UKCA marked 1121-CPR-UK-AE7854
• CE marked
• Made In Britain
• Manufactured from British steel and extruded aluminium
• Square cover
• Silver finish
• Body dimensions: 238mm x 60mm x 47mm
• Cover dimensions: 305mm x 75mm x 50mm
• Body weight: 2.4kg

The BM3SE Fire Door Closer with Electromagnetic Convenience

Electromagnetic door closers provide advanced functionality, making daily door usage smoother and more convenient, ultimately improving ease of access throughout a facility. This added user friendliness helps reduce the risk of fire doors being misused. Below, we explore the hold open and swing free functions offered by the two different models of this ARROW fire door closer.

ARROW BM3SE-HO with Electromagnetic Hold Open

The hold open version of the ARROW BM3SE is well suited to facilities that require flexible traffic flow. When connected to the building’s fire detection system, fire doors can be safely held open at angles beyond 80 degrees, allowing barrier free movement throughout busy environments.

As it is connected to the fire alarm the door will automatically close when the fire alarm is activated. This prevents the spread of smoke and flames, thus maintaining safety protocols without sacrificing convenience.

ARROW BM3SE-SF with Electromagnetic Swing Free

On the other hand, the swing free model allows doors to operate as if no closer is fitted making it ideal for bedroom doors in care homes. Similar to the hold open version, the swing free closer is linked to the fire alarm system, ensuring that doors will automatically close in the event of an emergency.

Door Closers Options for Every Door

ARROW offers a versatile range of door closing solutions tailored to suit various door types and installation requirements. For doors requiring an electromagnetic closer compatible with Fig. 61 and Fig. 66 installations, the ARROW 624EM door closer is an excellent option. For a cohesive appearance across your facility, the BM3S rack and pinion mechanical door closer pairs with this ARROW electromagnetic door closer, providing a consistent look on doors that don’t require the advanced functionality of electromagnetic closers.

Discover our full range of door closers for your facility, or contact our team for expert technical support.
