Boss TS7.004 Electromagnetic Hold Open/Swing Free Door Closer

Enhance Door Safety with Boss TS7.004 Door Closer

Discover a versatile, robust door closing solution with the Boss Door Controls TS7.004 magnetic door closer. Designed for high traffic commercial side hung doors, this easy to install closer combines safety, convenience, and compliance to meet the rigorous demands of fire safety regulations.

Key Product Features:

• Adjustable power size EN 3-4
• Adjustable closing speed
• Adjustable latching action
• Hold open or swing free function
• Matching cover and arm
• Semi-radiused cover
• Silver finish
• Operating voltage: 24V DC 95mA
• Universal unit installation:

           Fig. 1/61 – Pull side mounting/transom mounting

           Fig. 66 – Push side mounting (EN 3 only)

• Power size EN 3

          Suitable for doors up to 60kg and 950mm wide

Maximum opening angle: 180° Fig.1

Maximum opening angle: 170° Fig.66

• Power size EN 4

          Suitable for doors up to 80kg and 1100mm wide

          Maximum opening angle: 110°

• Fully certified to BS EN 1154 and BS EN 1155
• CE marked 2812-CPR-AE5012
• Certifire Approved CF 5023
• UKCA marked
• BS EN 1634-1 approved for use on fire rated doors up to FD120/EI 120
• Assists with meeting the requirements of BS8300 and Approved Document M
• Includes parallel arm bracket
• Body dimensions: 273mm x 58mm x 44mm
• Cover dimensions: 303mm x 74mm x 48mm

Electromagnetic Functionality: This Boss door closer with hold open and swing free function activates in response to the building's fire alarm system. This ensures doors close automatically during emergencies, delivering all-important fire compartmentation, and protecting escape routes.

Choose between settings for flexibility in door operation. Free swing closers allow doors to open and close as if no closer were fitted. This normality of operation provides a comforting feel for residential spaces such as bedroom doors in care homes. Make sure to fit an Automatic Fire Door Keep Clear sign for clear communication to all of the door’s function.

Adjustable Swing Speed: Customize the closing speed to match a range of door sizes, differing usage requirements, door location, and your facility’s users. Small adjustments make a big difference to the usability of a door and can extend the life of the closer if it is not being misused.

Compliance with Safety Standards: Fully CE marked, Certifire Approved, and tested to EN standards 1154 and 1155 for your peace of mind.

Closer Design and Installation

The Boss TS7.004 overhead door closer is robust and discreet in design, easily fitting in with a range of architectural designs and settings. This door closer is straightforward to install, equipped with all necessary fixings, and a parallel arm bracket. Whether retrofitting to existing doors or integrating into new build projects, setup is hassle-free with clear installation instructions.

Benefits of Electromagnetic Door Control

Embrace the power of control with the Boss TS7.004. Electromagnetic door closers provide enhanced safety by ensuring doors are securely held open during normal use, promoting accessibility and free movement. In the event of a fire, it responds to the fire alarm, closing doors to prevent the spread of smoke and fire.

Optimising Fire Safety and Accessibility

The Boss TS7.004 is an essential component of fire door ironmongery for safety and accessibility strategies for public and commercial buildings. Its reliable construction is perfectly suited for fire doors up to EI 120/FD120, ensuring they remain functional and compliant with fire regulations. The manufacturer recommends a program of 3-monthly maintenance so the unit operates at peak efficiency.

Secure and Compliant Door Closing

Step into a safer and more compliant built environment with the Boss TS7.004 electromagnetic door closer. Its numerous features and dependable performance make it a leading choice for anyone looking to enhance the safety and functionality of their facility.

Opt for the TS7.004 for educational institutions, hospitals, commercial buildings, and more. It maintains essential safety barriers without disrupting daily operations. Invest in a quality, compliant door closer and benefit from a top-performing door hardware solution that stands up to the challenges of your busy environment.
