GEZE THZ Comfort N4 Staircase Smoke Ventilation Control Unit

GEZE THZ Comfort N4: Smoke Ventilation Control for Stairwells

The GEZE THZ Comfort N4 is a single-zone smoke and heat extraction (SHEV) control unit designed for use in stairwells and small ventilation systems. It combines smoke extraction functionality with day-to-day comfort ventilation, making it ideal for residential buildings, stairwells, and escape routes that require both emergency and routine airflow control.

The THZ Comfort N4 control unit features a cast aluminium housing with an integrated ventilation button, allowing safe and immediate activation by building users. This smoke and heat extraction system control panel is often surface mounted and on display, thanks to its robust construction and built-in manual call point. For installations where access isn't required, a standard THZ N4 variant without buttons is also available and typically installed in cupboards or risers.

Key Product Features:

• MPN: 190783
• Controls 24V DC window actuators
• Suitable for smoke and heat extraction or natural ventilation systems
• Operating voltage: 230V AC
• Output voltage: 24V DC
• Maximum power consumption: 120W
• Maximum output current: 4.5A
• Illuminated buttons
• Integrated vent button
• IP30 rated
• Connection cross section/mains: 1.5mm²
• Motor cable wire size: 4mm²
• Rechargeable battery included
• Battery capacity: 2.3Ah
• Alarm group: 1
• Vent group: 1
• Residual ripple: 2%
• Operating temperature: -5°C to 40°C
• Conforms to EN 12101-10 and ISO 21927-9
• Approval: VdS
• Networking of several control units: forwarding of alarm and reset signals for linking up to 10 control units
• Signal outputs: 3 status contacts with settable parameters
• Settable parameters: service push buttons and 5 LEDs
• Finish: orange*
• Metal housing
• Dimensions: 140mm x 248mm x 85mm

*Other finishes are available as special orders, so contact us to enquire.

SHEV Activation and Emergency Smoke Control

This electric window control module connects with a range of compatible inputs, including smoke detectors, GEZE FT4 manual call points, fire alarm contacts, vent switches, and weather sensors. In an emergency, the THZ Comfort N4 can then open the connected window actuators.

The SHEV system is activated externally via a signal from the building’s fire alarm system. Activation is typically achieved using a volt-free normally open/common (NO/C) contact from a dedicated fire alarm interface or the auxiliary output of the fire panel. When the fire alarm is triggered, this contact closes to initiate the SHEV sequence.

Comfort Ventilation with Manual Override

Alongside its emergency functionality, the THZ Comfort N4 enables day to day ventilation. The integrated vent button provides direct manual control, which is ideal for improving air quality and supporting energy efficient temperature regulation.

For installations that require additional control points, compatible GEZE vent switches such as the LTA-24-AZ (24V) are available separately.

Pair with GEZE Actuators and Accessories

This model supports 24V drives with a combined output of up to 4.5A, making it suitable for installations with a single smoke ventilation zone. Complete your automatic window system with the wider GEZE range:

• GEZE E 250 NT: spindle drive window operator for roof windows
• GEZE Powerchain: ideal for large or heavy windows
• GEZE power supply modules
• Vent switches

Explore our selection of electric window actuators and accessories to build a compliant, dependable smoke ventilation system.
