CDVI V3SR Maglock Z and L Bracket | Internal Maglock Bracket

V3SR Maglock Z and L Brackets

The CDVI V3SR Z and L bracket set provides the correct fixing arrangement for installing compatible maglocks on inward opening doors. It allows the magnet and armature to be positioned correctly so the lock can achieve full contact and operate as intended.

These brackets are available in both standard and architectural options, allowing you to select the most suitable design for your door.

Key Product Features:

• Z and L brackets for CDVI maglocks with 300kg or 400kg holding force
• For inward opening doors
• Suitable for internal use only
• Adjustable
• Satin anodised aluminium finish
• Z Bracket Dimensions: 175mm x 50mm x 50.5mm to 101mm (adjustable)
• L Bracket Dimensions: 248mm x 50mm x 30mm

Standard Z&L Bracket Set:

• MPN: 300-ZL
• Weight: 0.77kg

Architectural Z&L Bracket Set:

• MPN: 300ZL-AC
• Discreet and aesthetic finish
• Weight: 0.96kg

Compatible CDVI Internal Maglocks Include:

• V3SR
• C3S11

Maglock Bracket Set for Inward Opening Doors

These maglock Z and L bracket sets are designed for installing a maglock on an inward opening door. They feature multiple fixing holes, allowing you to adapt the installation on site to suit your door and achieve accurate alignment.

The L bracket fixes the magnet to the frame, while the Z bracket positions the armature on the door, creating the correct offset for reliable locking.

For outward opening doors, a V3SR L bracket is a more suitable option. Our maglock guide explains installation methods in more detail and includes diagrams to help you choose the right bracket for your door.

Standard or Architectural Brackets for Maglocks

There are two Z and L bracket set options available. Choose between the standard or architectural versions.

The standard 300-ZL bracket set is suited to general installations where appearance is less of a priority. The 300ZL-AC architectural set provides a cleaner, more discreet finish for visible areas such as offices, hospitality settings, and commercial interiors.

Both options provide the same mounting function, so the choice comes down to the level of finish required for your installation.

Reliable Mounting for Internal Access Control

The CDVI V3SR Z and L bracket set provides a straightforward and effective way to mount internal maglocks on inward opening doors. When installed correctly, it supports consistent performance and helps ensure the maglock operates as expected within your access control system.
