BEA 4Safe Safety Sensor

The BEA 4Safe Safety Sensor is for use with automatic operators on swing doors for door safety and is available in two sizes.

These door mounted sensors have the following features:

• A field size of 400mm x 70mm at a 2m mounting height is provided by the four beams.
• Mountable from 1.1m - 3m according to floor reflectivity
• Additional Sensor Boards can be linked in order to extend the field of safety.
  Maximum of 4 Modules or 6 if 24V DC
• 2 Relay Output
• IP54 Rated - weather cover available
• Supply Voltage: 12V-24VAC with 10% tolerance
  12V-30V AC with a -5% or +10% tolerance.
• Maximum Contact Voltage - 30V DC
